Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

11
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
31
32
33
34
35
36
37
38
39
SRM-2100 1E S/N 001001 - 612595
35120152130 1 LOOP HANDLE ASY INCLUDES ITEMS 2-6
35121351730 1 GRIP, FRONT HANDLE
35121051730 1 HANDLE, FRONT
90024605030 2 SCREW 5X30
90024206035 4 SCREW 6X35
90050000006 4 NUT 6
SRM-2100 1E S/N 612596 & UP
P021000020 1 LOOP HANDLE ASY INCLUDES ITEMS 7-14
35121666230 1 GRIP, FRONT HANDLE
35120566230 1 HANDLE, FRONT
90060000005 2 WASHER
88995021060 2 SCREW
90024205035 4 SCREW 5X35
35122507130 1 BRACKET, HANDLE
90050000005 4 NUT 5
89016054130 1 LABEL, CAUTION
30120029430 1 BAND INCLUDES ITEM 17
90024205014 1 SCREW 5X14
16340155630 1 SWITCH, IGNITION
17800352130 1 THROTTLE BRACKET SET INCLUDES ITEMS 20-22
90050000005 2 NUT 5
90024205035 1 SCREW 5X35
90024205025 1 SCREW 5X25
17801352630 1 SPRING, THROTTLE TRIGGER LOCKOUT
17809052630 1 LEVER, THROTTLE TRIGGER LOCKOUT
17801252630 1 LOCKOUT, THROTTLE TRIGGER
17801052130 1 CONTROL, THROTTLE
17804342230 1 SPRING, THROTTLE RETURN
17812750330 1 TUBE
SRM-2100 1E S/N 001001-512721
17800144430 1 CABLE, THROTTLE
SRM-2100 1E S/N 512772 & UP
17800156730 1 CABLE, THROTTLE
90050200006 2 NUT 6
35121352130 1 GRIP, FRONT HANDLE
61027252130 1 BAND 25 INCLUDES ITEMS 33-34
90024205030 1 SCREW 5X30
90050000005 1 NUT 5
61060944730 1 DRIVE SHAFT HOUSING ASY INCLUDES ITEMS 36-37
61024644730 2 FIXTURE, LINER
61021744730 1 LINER, FLEXIBLE
61001344730 1 SHAFT, FLEXIBLE
89015204930 1 LABEL, ALIGNMENT
SRM-2100 TYPE 1E
HANDLE, STOP SWITCH, THROTTLE CABLE, DRIVESHAFT
Part Number New To This Edition =
081801

Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 Specifications

General

Category	Brush Cutter
Model	SRM-2100
Displacement	21.2 cc
Type	TYPE 1E
Fuel Mix Ratio	50:1
Engine Type	2-Stroke
