Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001

19
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
A
B
SRM-2100 TYPE 1E & SRM-2110 TYPE 1E S/N 001001 - 008042
12520049030 1 CARBURETOR C1U-K47 INCLUDES THE FOLLOWING:
12534452130 2 SCREW
12534213210 1 COVER, METERING DIAPHRAGM
A B 1 DIAPHRAGM, METERING
A B 1 GASKET, METERING DIAPHRAGM
12533942030 1 SCREW
A 1 PIN, METERING ARM
A 1 LEVER, METERING
A 1 SPRING, METERING LEVER
A 1 VALVE, INLET NEEDLE
A 1 PLUG, WELCH
12532715130 1 CLIP
12537649030 1 NOZZLE, CHECK VALVE
12531649030 1 VALVE, THROTTLE
12531413930 1 SCREW
12531942030 2 SPRING, NEEDLE
12535320560 2 WASHER
12531807360 1 NEEDLE, LO SPEED
12532909860 1 CAP, LIMITER - LO SPEED
12532007360 1 NEEDLE, HIGH SPEED
12532939030 1 CAP, LIMITER - HIGH SPEED
12531342030 1 SPRING, THROTTLE RETURN
12531749030 1 SHAFT, THROTTLE
12532713930 1 CLIP
12537242030 1 SWIVEL
A 1 STRAINER
A B 1 DIAPHRAGM, FUEL PUMP
A B 1 GASKET, FUEL PUMP
12538313310 1 BASE, PURGE
12537813930 1 PIECE, FRICTION
12533413930 1 SCREW, IDLE ADJUST
12538108660 1 PUMP, PURGE
12536311610 1 RETAINER, PURGE PUMP
12531011610 2 SCREW
12530049030 1 REPAIR KIT
12530349030 1 GASKET/DIAPHRAGM KIT
CARBURETOR
