Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001

21
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
A
B
2100 TYPE 1E S/N 008043 & UP & SRM-2110 TYPE 1E S/N 501001 & UP
12520013312 1 CARBURETOR C1U-K52 INCLUDES THE FOLLOWING ITEMS:
12534452130 2 SCREW
12534213210 1 COVER, METERING CHAMBER
A B 1 DIAPHRAGM, METERING
A B 1 GASKET, DIAPHRAGM METERING
12533942030 1 SCREW, METERING PIN
A 1 PIN, METERING LEVER
A 1 LEVER, METERING
A 1 SPRING, METERING LEVER
A 1 VALVE, NEEDLE
A 1 PLUG, WELCH
12532715130 1 CLIP, THROTTLE SHAFT
12537649030 1 NOZZLE, CHECK VALVE
12531649030 1 VALVE, THROTTLE
12531413930 1 SCREW, THROTTLE VALVE
12532013310 1 NEEDLE, HIGH SPEED
12532939030 1 CAP, LIMITER H.S.
12531813310 1 NEEDLE, IDLE
12532909860 1 CAP, LIMITER L.S.
12531342030 1 SPRING, THROTTLE RETURN
12531713310 1 SHAFT, THROTTLE
12532713930 1 CLIP, SWIVEL
12537242030 1 SWIVEL
A 1 STRAINER
A B 1 DIAPHRAGM, FUEL PUMP
A B 1 GASKET, FUEL PUMP
12538313310 1 BASE, PURGE
12533306960 1 SPRING, IDLE ADJUSTER
12533406960 1 SCREW, IDLE ADJUST
12538108660 1 PUMP, PURGE
12536311610 1 RING
12531011610 2 SCREW
12530013310 1 REPAIR KIT
12530313310 1 GASKET/DIAPHRAGM KIT
CARBURETOR
