25
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
SRM-2100 TYPE 1E
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
P021000460 1 BRACKET SET INCLUDES ITEMS 2-3
90014205025 4 BOLT 5X25
90014206030 2 BOLT 6X30
35121005530 1 HANDLE - LEFT
35101005530 1 HANDLE - RIGHT
35131122430 1 GRIP, HANDLE - LEFT
35131522130 1 GRIP, HANDLE - RIGHT
17802451830 1 BRACKET, THROTTLE
17811005330 1 SCREW
90024205025 1 SCREW 5X25
90056000005 1 LOCKNUT 5
90050000005 1 NUT 5
16340149230 1 SWITCH, IGNITION
17801006460 1 TRIGGER, THROTTLE
17804305230 1 SPRING, RETURN
17800141330 1 CABLE, THROTTLE
17810605330 1 BAND
90022005010 1 SCREW 5X10
17811104930 1 CLAMP
17812708030 1 TUBE
90050300006 2 NUT 6
90060000006 2 WASHER 6
30120021330 1 HOOK
90010005012 1 BOLT 5X12
69900023431 1 SHIELD ASY INCLUDES ITEMS 26-31
69901523431 1 BRACKET
90060500005 4 WASHER, SPRING 5
90050000005 4 NUT 5
69901023531 1 SHIELD
90022005008 2 SCREW 5X8
90024205010 3 SCREW 5X10
89016841030 1 LABEL, CAUTION
89011848830 1 LABEL, ECHO
61033808930 1 PLATE, FITTING - UPPER
61031404131 1 PLATE, FITTING - LOWER
90051100010 1 NUT 10, LEFT
90030020022 1 PIN, SPLIT (10 PER PACKAGE)
30100052131 1 HARNESS ASY
30110541830 1 PAD, WAIST
OPTIONAL COMBINATION U-HANDLE/BLADE
CONVERSION KIT 99944200451
