Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

3
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
ENGINE, CRANKCASE, CYLINDER COVER
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
OPTIONAL ENGINE REPOWER
SB1026 1 SHORT BLOCK INCLUDES ITEMS 2-17
SRM-2100 TYPE 1E - S/N 001001-671697, SRM-2110 TYPE 1E - S/N 001001- 503538
10101106562 1 CYLINDER
SRM-2100 TYPE 1E - S/N 671698 & UP, SRM-2110 TYPE 1E - S/N 503539 & UP
A130000011 1 CYLINDER
90016205022 2 BOLT 5X22
10101044332 1 GASKET, CYLINDER ALSO CONTAINED IN GASKET KIT 88900042033
10000048730 1 PISTON KIT INCLUDES ITEMS 6-9
10001105330 1 RING, PISTON
10001311520 1 PIN, PISTON
10001504630 2 CIRCLIP, PISTON PIN
10001411520 2 SPACER, PISTON PIN
10010054130 1 CRANKSHAFT ASY INCLUDES ITEM 11
10001251230 1 BEARING, NEEDLE
10020452130 1 CRANKCASE KIT INCLUDES ITEMS 13-17
10021242030 2 OILSEAL
10021503930 2 PIN, DOWEL
90081036201 2 BEARING, BALL 6201
10024242030 1 GASKET, CRANKCASE ALSO CONTAINED IN GASKET KIT 88900042033
90016205028 3 SCREW 5X28
90023805016 1 SCREW 5X16
15991254130 1 GUARD, TOP
10151448930 1 COVER, CYLINDER
90016204016 6 SCREW 4X16
GASKET KIT
88900042033 1 GASKET KIT - CONTAINS THE FOLLOWING:
10024242030 1 GASKET, CRANKCASE
10101044332 1 GASKET, CYLINDER
13001042032 1 GASKET, INTAKE
13001642031 1 GASKET, INTAKE
14586642031 1 GASKET, EXHAUST
V104000002 1 GASKET, EXHAUST
V104000160 2 GASKET, EXHAUST
