Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

5
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
IGNITION, FAN CASE
1
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14
14
15
16
17
18
19
20
21
SRM-2100 TYPE 1E & SRM-2110 TYPE 1E - S/N 001001-008042
15660152130 1 COIL, IGNITION
15680144731 1 FLYWHEEL
SRM-2100 TYPE 1E - S/N 008043 & UP & SRM-2110 TYPE 1E - S/N 501001 & UP
15662609660 1 COIL, IGNITION
15680109660 1 FLYWHEEL
90016204022 2 SCREW 4X22
16201052830 1 LEAD
15611240630 1 GROMMET
15901201620 1 CAP, SPARK PLUG
15901103432 1 COIL, SPARK PLUG CAP
15901010630 1 PLUG, SPARK BPM-7A
61090355230 1 HOLDER KIT INCLUDES ITEMS 10-12
90014205025 2 BOLT 5X25
61092227432 1 HOLDER - UPPER
61092355230 1 HOLDER - LOWER
61091055230 1 CUSHION
89011554130 1 LABEL, MODEL SRM-2100
89011254130 1 LABEL, MODEL SRM-2110
10150352131 1 FAN COVER ASY
90016204016 6 SCREW 4X16
90070100012 1 CIRCLIP 12
90080796001 2 BEARING, BALL 6001
90070200028 1 CIRCLIP 28
17500548931 1 DRUM, CLUTCH
17500049030 1 CLUTCH ASY
081801

Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 Specifications

General

Category	Brush Cutter
Model	SRM-2100
Displacement	21.2 cc
Type	TYPE 1E
Fuel Mix Ratio	50:1
Engine Type	2-Stroke
