Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 User Manual

9
SRM-2100 T1E & SRM-2110 T1E
ITEM PART NUMBER QTY DESCRIPTION REMARKS
INTAKE, EXHAUST
1
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
22
23
21041752730 1 BOLT, WING
89012106360 1 LABEL, CHOKE
13031306563 1 LID, AIR CLEANER
13031054130 1 FILTER, AIR - HEAVY DUTY
90024205065 2 SCREW 5X65
12901152730 1 PLATE, PREVENT
13030706561 1 CASE, AIR CLEANER
SRM-2100 TYPE 1E & SRM-2110 TYPE 1E - S/N 001001 - 008042
12520049030 1 CARBURETOR C1U-K47 SEE PAGES 18-19
SRM-2100 TYPE 1E - S/N 008043 & UP, SRM-2100 TYPE 1E - 2110 1E S/N 501001 & UP
12520013311 1 CARBURETOR C1U-K52 SEE PAGES 20-21
13001642031 1 GASKET, INTAKE ALSO CONTAINED IN GASKET KIT 88900042033
90023805020 2 SCREW 5X20
13001742031 1 INSULATOR
90050000005 2 NUT 5
13001042032 1 GASKET, INTAKE ALSO CONTAINED IN GASKET KIT 88900042033
14580054130 1 MUFFLER ASY INCLUDES ITEMS 15 -21
V104000160 2 GASKET, MUFFLER ALSO CONTAINED IN GASKET KIT 88900042033
14587144331 1 COVER, MUFFLER
90060000005 2 WASHER 5
90010505055 2 BOLT 5X55
14586240630 1 SCREEN, MUFFLER
14587642030 1 GUIDE, EXHAUST - INNER
90023804010 3 SCREW 4X10
SRM-2100 TYPE 1E - S/N 001001-671697, SRM-2100 TYPE 1E - 2110 1E S/N 001001-503301
14586642031 1 GASKET, EXHAUST ALSO CONTAINED IN GASKET KIT 88900042033
14586354130 1 GUIDE, EXHAUST - OUTER
SRM-2100 TYPE 1E - S/N 671698 & UP, SRM-2100 TYPE 1E - 2110 1E S/N 503302 & UP
V104000002 1 GASKET, EXHAUST ALSO CONTAINED IN GASKET KIT 88900042033
A313000000 1 GUIDE, EXHAUST - OUTER

Echo SRM-2100 TYPE 1E - PARTS CATALOG SERIAL NUMBER 001001 Specifications

General

Category	Brush Cutter
Model	SRM-2100
Displacement	21.2 cc
Type	TYPE 1E
Fuel Mix Ratio	50:1
Engine Type	2-Stroke
