Echo SRM-231

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- RB-K701A021000720
ROTOR COVER ASY1P0050012301
NUT1P0050001202
SCREW3125344139313
SCREW, CABLE ADJUST1P0050007004
SWIVEL1P0050012405
RING, RETAINING1P0050001906
SCREW, IDLE ADJUST1P0050001007
O-RING1P0050002808
BODY, CARBURETOR
1
1------------------9
CAP, LIMITER1P00500127010
NEEDLE - HIGH SPEED1P00500126011
BASE, PURGE1P00500093012
SCREW, PURGE BASE1P00500027013
BULB, PURGE11253810866014
RETAINER, PURGE BULB1P00500025015
SCREW, PURGE BULB RETAINER41253106183016
COVER, DIAPHRAGM11253425213017
SCREW21253445213018
SCREW, METERING LEVER PIN11253394203019
INCLUDES ITEMS 21-30REPAIR KIT1P00500095020
GUIDE, ROLLER1P00500100021
PIN, METERING LEVER1------------------22
VALVE, INLET NEEDLE1------------------23
LEVER, METERING1------------------24
SPRING1------------------25
STRAINER1------------------26
DIAPHRAGM, PUMP1------------------27
GASKET, PUMP1------------------28
GASKET, DIAPHRAGM1------------------29
DIAPHRAGM, METERING1------------------30
INCLUDES ITEMS 32-35DIAPHRAGM/GASKET KIT1P00500055031
DIAPHRAGM, PUMP1------------------32
GASKET, PUMP1------------------33
GASKET, DIAPHRAGM1------------------34
DIAPHRAGM, METERING1------------------35
Footnotes
1: NOT AVAILABLE SEPARATELY
99922203528_231/06 - 11 - REVISED 10/19/11
Table of Contents Part Number Index
SRM-231 Trimmer Carburetor -- RB-K70 S/N: 06011857 - 06015096
