Echo SRM-231

REMARKSDESCRIPTIONQTYPART NUMBERITEM
CARBURETOR -- RB-K70A1A021000721
SCREW3125344139311
SCREW1125344521302
SCREW, CABLE ADJUST1P0050013303
RING, RETAINING1P0050001904
SWIVEL1P0050012405
SCREW, IDLE ADJUST1P0050001006
ROTOR COVER ASY1P0050016207
O-RING1P0050002808
SCREW, PURGE BULB RETAINER4125310618309
RETAINER, PURGE BULB1P00500025010
BULB, PURGE11253810866011
SCREW, PURGE BASE1P00500027012
BASE, PURGE1P00500093013
CAP, LIMITER1P00500127014
NEEDLE - HIGH SPEED1P00500126015
SCREW21253445213016
COVER, DIAPHRAGM11253425213017
SCREW, METERING LEVER PIN11253394203018
INCLUDES ITEMS 21-29REPAIR KIT1P00500095019
GUIDE, ROLLER1P00500100020
GASKET, PUMP1------------------21
DIAPHRAGM, PUMP1------------------22
STRAINER1------------------23
SPRING, METERING LEVER1------------------24
VALVE, INLET NEEDLE1------------------25
PIN, METERING LEVER1------------------26
LEVER, METERING1------------------27
GASKET, DIAPHRAGM1------------------28
DIAPHRAGM, METERING1------------------29
INCLUDES ITEMS 31-34DIAPHRAGM/GASKET KIT1P00500055030
GASKET, PUMP1------------------31
GASKET, DIAPHRAGM1------------------33
DIAPHRAGM, PUMP1------------------32
DIAPHRAGM, METERING1------------------34
BODY, CARBURETOR
1
1------------------35
Footnotes
1: NOT AVAILABLE SEPARATELY
99922203528_231/06 - 13 - REVISED 10/19/11
Table of Contents Part Number Index
SRM-231 Trimmer Carburetor -- RB-K70A S/N: 06015097 - 06999999
