Echo SRM-231 Parts Catalog

REMARKSDESCRIPTIONQTYPART NUMBERITEM
INCLUDES ITEMS 2-3CLAMP KIT1610272521301
SCREW - 5X281900242050282
NUT - 51900500000053
GRIP, HANDLE1351213521304
INCLUDES ITEMS 6-8CONTROL HANDLE KIT1178003521305
SCREW 5X351900242050356
SCREW - 5X251900242050257
NUT2900500000058
INCLUDES ITEM 10CLAMP KIT1301200294309
SCREW - 5X1419002420501410
TUBE, PROTECTIVE - CORRUGATED1V47500085011
CABLE, THROTTLE1V43000073012
TRIGGER, THROTTLE11780105213013
SPRING, TRIGGER11780434223014
LOCKOUT, TRIGGER11780125273015
LEVER, TRIGGER LOCKOUT11780905263216
SPRING, THROTTLE LOCKOUT11780135263017
INCLUDES ITEMS 19-20IGNITION SWITCH ASY1A44000028018
SCREW - 3X101915450301019
KNOB, SWITCH - ORANGE1A44400002020
99922203528_231/06 - 33 - REVISED 10/19/11
Table of Contents Part Number Index
SRM-231 Trimmer Control Handle,Throttle Cable, Ignition Switch
