Echo SRM-231

REMARKSDESCRIPTIONQTYPART NUMBERITEM
THUMBSCREW1210417527301
COVER, AIR CLEANER - GRAY1130313065632
COVER, AIR CLEANER - BLACK1130313058633
FILTER, AIR - DOUBLE LAYER
1
1A2260014104
FILTER, AIR - SINGLE LAYER
2
1130310541305
SCREW - 5X602900242050606
PLATE, PREVENT1129011527307
CASE, AIR CLEANER - GRAY1P0210009918
CASE, AIR CLEANER - BLACK1P0210044809
CARBURETOR
3
1------------------10
GASKET, INTAKE
4
11300101341011
SCREW - 5X2529001620502512
INSULATOR, INTAKE11300175643113
GASKET, INTAKE
5
11300105593014
Footnotes
1: Included In RePower TUNE-UP KIT
2: OPTIONAL
3: See Carburetor Diagrams For Details
4: Also Included In GASKET KIT
5: Included In GASKET KIT
99922203528_231/06 - 7 - REVISED 10/19/11
Table of Contents Part Number Index
SRM-231 Trimmer Intake
