63
SRM-2655/2655SI
E
N
G
L
I
S
H
D
E
U
T
S
C
H
I
T
A
L
I
A
N
O
SRM-2655 SRM-2655SI
LULU
Mass :
unit without cutting attachment, empty tank kg 5.4 5.9 5.6 6.1
unit with specified cutting attachment, empty tank kg 5.7 6.3 5.9 6.5
unit with specified cutting attachment, full tank kg 6.2 6.7 6.4 6.9
Volume : fuel tank L 0.65
Cutting attachment :
nylon line head Z5 - Z5 -
line diameter 3.0 - 3.0 -
line length m 5 × 1 line - 5 × 1 line -
thread Left-handed M10 × 1.25 Left-handed M10 × 1.25
specified blade diameter mm - 230 - 230
specified blade thickness mm - 2.0 - 2.0
number of cutting teeth - 3 - 3
blade centre hole diameter mm - 25.4 - 25.4
blade rotational speed at maximum allowable
engine speed r/min - 10,000 - 10,000
Gear ratio : gear ratio and lubrication 1.36 reduction and good quality lithium grease
Rotational direction of output shaft seen from above : Anticlockwise
External dimensions :
length mm 1,755 1,760 1,785 1,790
width mm 360 690 360 690
height mm 350 460 350 460
Engine :
type Air cooled two stroke single cylinder
engine displacement mL(cm³) 25.4
maximum shaft brake power, measured in
accordance with ISO 8893 kW 0.77
engine speed at maximum engine power r/min 7,000
recommended maximum engine speed r/min 10,000
output shaft speed r/min -
recommended engine idling speed r/min 2,700
engine speed at beginning of clutch engagement r/min 3,400
carburettor Diaphragm type
ignition Flywheel magneto - TCI system
spark plug NGK BPMR7A
starter Recoil starter START
clutch Automatic centrifugal clutch
Fuel : Regular grade petrol. Minimum 89 Octane
unleaded petrol is recommended. Do not use fuel
containing methyl alcohol or more than 10 % of
ethyl alcohol.
oil Two stroke, air-cooled engine oil. 50 : 1 for ISO-L-
EGD Standard (ISO/CD 13738), JASO FC grade
and ECHO Premium 50 : 1 oil.
ratio 50 : 1 (2 %)
fuel consumption at maximum engine power L/h 0.70
specific fuel consumption at maximum
engine power g/(kW•h) 672
Sound pressure level : (EN 27917) LpAav = dB(A) 92 90 92 90
Guaranteed sound power level :
(2000/14/EC) LWA = dB(A) 111 106 111 106
Vibration levels : (ISO 7916)
idling m/s² 6.2 4.3 6.2 4.3
racing m/s² 4.8 4.3 4.8 4.3
GB
SPECIFICATIONS
Specifications, descriptions and illustrative material in
this literature are as accurate as known at the time of
publication, but are subject to change without notice.
Illustrations may include optional equipment and
accessories, and may not include all standard
equipment.
