Echo SRM-3605(SI)

SRM-3155(SI),3605(SI)
1. Cylinder, Crankcase, Piston, Fan Cover
KEY LV PART NUMBER Q'TY DESCRIPTION REMARKS NOTE1
NOTE2
19 100000-55830 1 PISTON KIT
Sus. by P021-
007410
19 100000-55831 1
PISTON KIT
Sus. by P021-
007410
19 100000-55832 1
PISTON KIT
Sus. by P021-
007410
19 P021-007410 1
PISTON KIT
SRM-3605/3605SI
20 + 100011-16131 2
RING, PISTON
SRM-3155/3155SI
20 + 100011-42230 2
RING, PISTON
SRM-3605/3605SI
21 + 100013-27430 1
PIN, PISTON
22 + 100015-03930 2
CIRCLIP, PISTON PIN
Sus. by 100015-
03931
22 + 100015-03931 2
CIRCLIP, PISTON PIN
23 + 100012-16131 1
BEARING, NEEDLE
24 + 100014-53630 2
SPACER, PISTON PIN
25 100100-55430 1
CRANKSHAFT ASSY
30 100204-55430 1
CRANKCASE KIT
31 + 100213-05530 2
OILSEAL
ISCD 12 22 7
32 + 100215-03930 4
PIN, DOWEL
33 + 900810-36201 2
BEARING, BALL 6201
6201/C3
Sus. by 94035-
36201
33 + 94035-36201 2
BEARING BALL
6201X3JR2C3
34 + 100242-55430 1
GASKET, CRANKCASE
- 2 -
