2 SERVICE HINT
2-1 Gear case construction
7
SERVICE INFORMATION
SRM-3805
SRM-4605
Drive gear
Driven gear
PTO shaft
Nut
Adapter plate (L)
Gear case
Adapter plate (U)
Cover plate
Dust seal plate
O-ring
