Echogear EGMF2 - Drill Holes; Secure Wall Plate

11
7/32 in.
(5.5 mm)
2¾
in. (6.9 cm)
Bit
06
08
Continue
STEP 2.5
on PAGE 14
CAUTION: DO NOT over-tighten
the lag bolts
07
. Tighten only enough to
securely fasten the wall plate
06
to the wall.
07
Use bottom
lag bolt
07
to level.
2X
Drill Holes Secure Wall Plate
STEP 2A.3 STEP 2A.4
