EchoLife ET655 IP Phone User Manual
3 Installing the ET655
11
Table 3-1 Description of the connectors
No.
Connector
Description
(1)
EXT port
A port used to connect an expansion board for increasing
multi-purpose keys. In this way, you can call a user by
pressing one key.
(2)
PC port
The port is the 10/100 Mbit/s RJ-45 PC port. You can
use the straight-through cable to connect the PC port.
When using the PC phone, you can configure the port.
(Optional)
(3)
LAN port
The port is the 10/100 Mbit/s RJ-45 LAN port. You need
to use the straight-through cable to connect the LAN
port to the Ethernet port.The phone supports PoE
(802.3af) power. In this case, you must connect the port
to the switch supporting PoE power.
(4)
Power port
5Vpower port. After the network cable connection is
complete, use the special power adapter of the phone to
connect the power port and power to switch on the
phone.
(5)
Headset port
RJ-9 port. If you want to use the headset for
communication, install the headset socket to the port.
(6)
Handset port
RJ-9 port. If you want to use the headset for
communication, install the headset socket to the port.
Starting the ET655
After the ET655 is powered on, a progress bar is displayed on its screen. This progress
bar disappears after the startup page is accessed.
Safety Compliance
The ET655 complies with the Federal Communications Commission (FCC),
Confermite Europeenne (CE), China Compulsory Certification (CCC), and various
safety standards. The ET655 specialized power adapter is compliant with the
Underwriter Laboratories (UL) standard. Use only the matching power adapter
provided with the package. The manufacturer’s warranty does not cover damages to the
phone caused by unsupported power adapters.
