EchoLife ET655 IP Phone User Manual
The ET655 operates in two modes:
DHCP/PPPoE Mode:
All the field values for the static IP mode are not available
even though they are stored in the Flash memory. The
ET655 acquires its IP address from the first DHCP server
that the ET655 detects on its LAN. To use the PPPoE
feature, set the PPPoE account. The ET655 establishes a
PPPoE session if any of the PPPoE fields are set.
Host Name and Domain Name: The special DHCP options
that are added to the DHCP Discover and DHCP Request
after configuration.
Preferred DNS: The ET655 uses the DNS server if
Preferred DNS is configured
Static IP Mode: Configure all of the following fields: IP
address, Subnet Mask, Gateway, Default Router IP
address, DNS Server 1 (primary), and DNS Server 2
(secondary). The fields are set to 0 by default except that the
IP address is set to 192.168.0.160 by default.
This parameter is set to perform the 802.1X authentication
when the IP phone is connected to a switch. You can click
Disable to disable the authentication function, and click
EAP-MD5 to perform the registration authentication.
Identify
ID used during the 802.1x authentication
MD5 Password
MD5 password used during the 802.1X authentication
This parameter is set for specifying function modes of line keys.
By default, the value of Key Mode is Line, which is used by
common lines. If the value of Key Mode is Shared Line, it
indicates that the BroadSoft SCA functions are enabled and that
accounts scattered in various areas can share the line.
The optional values are Speed Dial, Busy Lamp Field(BLF),
Presence Watacher, eventlist BLF, Speed Dail via active
account, and Dial DTMF.
Each key corresponds to an account, that is, a user number is set
for each key.
