If the name should be changed, the DP300 features a collection of pre-programmed names which can
be assigned to any output, depending on its use in the sound system.
Band 1-6
L Low, L Mid, L High
R Low, R Mid, R High
C Low, C Mid, C High
Subs, Low, Lo Mid, Mid, Hi Mid, High
Mid+High
2"Horn, 1"Horn
Bullet
Flat
Unused
Bar, BStage
Delay
Centre
Mono
Aux
10", 12", 15", 18", 21", 24"
1.5"Hn
Delay1, Delay2, Delay3, Delay4, Delay5, Delay6
L Subs, C Subs, R Subs
To select the desired name, use the encoder wheel or the ? and ? keys.
2. Signal Source
Each output must have an assigned input, which represents the source signal for all consequent
processing tasks. Each output can have one of following assigned inputs:
Input INA (CH1)
Input INB (CH2)
Input IN SUM A+B
OUT 1 Band 1
Srce IN A
In this example the unit is in Mono mode and the Output 1 (OUT1) has INA (CH1) assigned as its input.
In general, Input A&B should be selected in the modes which allow stereo linking. In Mono mode or in
the stereo modes without linking, inputs can be freely assigned to each output.
