Ecler eMOTUS5OD - TECHNICAL SPECIFICATIONS

10
9. TECHNICAL SPECIFICATIONS
eMOTUS5OD
System
Effective frequency range
1
75 Hz - 20 kHz (-10dB)
Coverage angle
2
150° x 150° (HxV)
Power handling
40W RMS / 160W Peak
Sensitivity
3
85dB (1W/1m)
Maximum SPL
4
101dB continuous / 107dB peak
Power options
100V: 30 / 15 / 7,5 / 3,75W & 8Ω
70V: 15 / 7.5 / 3.75 /1,8W & 8Ω
Recommended amplifier power
80W (8Ω)
Transducers
Ways
2-ways, full range
Low frequency driver
5’’ woofer
High frecuency driver
1’’ coaxial tweeter
Nominal impedance
8Ω
Physical
Connection type
2-terminal Euroblock connector (Input)
Power type selector
Selectable transformer tap
Installation options
Surface, desktop
Environmental
IP65 rated
Enclosure material
ABS cabinet
Grille material
Aluminium grille
Mounting system
ABS bracket
Finished color
White (RAL 9003) or black (RAL 9005)
Included accessories
Wall-mount bracket, adhesive legs, back rubber
cover & security steel cable
Optional accessories
PCS124 cluster-mount system
Dimensions
Not including brackets (HxWxD):
180 x 173 x 181mm / 7.1” x 6.8” x 7.1”
Including brackets (HxWxD):
180 x 173 x 248mm / 7.1” x 6.8” x 9.8”
Weight
Not including brackets: 2,2 kg. / 4.9 lb.
Including brackets: 2,5 kg. / 5.5 lb.
Pieces per box
2 units with included accessories
Shipping dimensions
HxWxD: 220 x 230 x 460mm / 8.7” x 9.1” x 18.1”
Shipping weight
5,0 kg. / 11.0 lb.
1
10dB below the sound pressure level at specified sensitivity
2
6dB below the sound pressure level than that at the direction of maximum level, Average from 1 kHz to 4 kHz.
3
Measured on-axis, 2,83V, far field and referenced to 1 meter by inverse square law. Average from 100 Hz to 10 kHz.
4
Calculated from sensitivity and power handling specifications, exclusive of power compression
