PARTS LIST: PRINTED CIRCUIT 11.1012.03.00
Code
Description
Reference
FCRJC5100000
10k
R382
FCXR53100000
1k0
R383
FCXR51750000
75.0
R384
FCXR51750000
75.0
R385
FCXR55100000
100k
R388
FCXR55100000
100k
R389
FCXR55100000
100k
R390
FCXR55100000
100k
R391
FCXR55100000
100k
R392
FCXR55100000
100k
R393
FCXR55100000
100k
R403
FCXR55100000
100k
R404
FCXR55100000
100k
R405
FCXR55100000
100k
R406
FCXR55100000
100k
R408
FCXR55100000
100k
R409
FCXR53121000
1k21
R410
FCXR53121000
1k21
R411
FCXR54215000
21k5
R412
FCXR54215000
21k5
R413
FCXR55237000
237k
R414
FCXR54215000
21k5
R415
FCXR54215000
21k5
R416
FCXR54215000
21k5
R417
FCXR54215000
21k5
R418
FCXR54383000
38k3
R419
FRPOTD450100
100kB
R420
FCXR54215000
21k5
R421
FCXR54215000
21k5
R422
FCXR54383000
38k3
R423
FCXR54215000
21k5
R424
FCXR54215000
21k5
R425
FCXR54215000
21k5
R426
FCXR54215000
21k5
R427
FCXR53316000
3k16
R429
FCXR55100000
100k
R430
FCXR55100000
100k
R431
FCXR55100000
100k
R432
FCXR55100000
100k
R433
FCXR55100000
100k
R434
FCXR55100000
100k
R435
FCXR55100000
100k
R436
FCXR55100000
100k
R437
FCXR55100000
100k
R438
FCXR55100000
100k
R439
FCXR54316000
31k6
R441
FCPR21005100
10kAx2
R444
FCPR21005100
10kAx2
R445
FCXR54215000
21k5
R446
FCXR54215000
21k5
R447
FCXR55100000
100k
R448
FCXR54215000
21k5
R452
FCXR54215000
21k5
R453
FCXR54215000
21k5
R456
FCXR54215000
21k5
R457
FCXR55100000
100k
R458
