PARTS LIST: PRINTED CIRCUIT 11.1010.02.00
Code
Description
Reference
FCCE10000000
47u/16
C267
FCCE10000000
47u/16
C268
FCCE25047000
47u/50
C287
FCCE25047000
47u/50
C288
FCXCD4100000
100n
C289
FCXCD4100000
100n
C290
FCXCD4100000
100n
C307
FCXCD4100000
100n
C333
FCXCD4100000
100n
C334
FCXCD4100000
100n
C335
FCXCD4100000
100n
C336
FCXCD4100000
100n
C337
FCXCD4100000
100n
C338
FCCE25047000
47u/50
C339
FCCE25047000
47u/50
C340
FCCI01010000
Printed Board 11.1010
CI101
FCXZ00007500
Z7.5V
D117
FCXZ00007500
Z7.5V
D118
FCXDDBAS1600
BAS16
D119
FCXDDBAS1600
BAS16
D120
FCIC45560000
NJM4556D
IC127
FCIC43101000
LM431AC
IC128
FCIC07201000
TL072
IC129
FCIC07401000
TL074
IC134
FCIC07401000
TL074
IC136
FCCTM1006000
S6B-EH
J115
FCCTM1005000
S5B-EH
J136
FCPR21005100
10kAx2
R102
FCXR55100000
100k
R366
FCXR55100000
100k
R367
FCXR53261000
2k61
R368
FCXR53261000
2k61
R369
FCXR54215000
21k5
R376
FCXR54215000
21k5
R377
FCXR51750000
75.0
R386
FCXR51750000
75.0
R387
FCXR51750000
75.0
R394
FCXR51750000
75.0
R395
FCXR54215000
21k5
R396
FCXR52562000
562
R397
FCXR54316000
31k6
R398
FCXR53422000
4k22
R399
FCXR54511000
51k1
R400
FCXR54237000
23k7
R401
FCXR54100000
10k0
R402
FCXR54100000
10k0
R407
FCXR53147000
1k47
R428
FCPR12005000
500kD
R440
FCXR53422000
4k22
R442
FCXR53121000
1k21
R443
FCXR53196000
1k96
R449
FCXR54100000
10k0
R450
FCXR54100000
10k0
R451
FCXR54100000
10k0
R454
FCXR54100000
10k0
R455
FCXR54100000
10k0
R468
40-0140-0100 M09-04 NUO2.xls 1 of 2
