Ecler VIC6 - 8 Technical Characteristics

11
8. TECHNICAL CHARACTERISTICS
VIC6
VIC6X
VIC8
VIC8X
VICSB8
VICSB8X
Nominal low impedance
8Ω 8Ω 8Ω
RMS power
40W 60W 80W
100V Transformer Taps
40 / 20 / 10 / 5W 60 / 30 / 15 / 7.5W 60 / 30 / 15 / 7.5W
70V Transformer Taps
40 / 20 / 10 / 5 /
2.5W
60 / 30 / 15 / 7.5 /
3.75W
60 / 30 / 15/ 7.5 /
3.75W
Frequency response
50Hz – 20kHz 35Hz – 20kHz
35Hz – 2kHz
(with crossover)
Sensitivity 1W/1m
89dB 88dB 87dB
External diameter
232mm 282mm 282mm
Internal diameter
205mm 245mm 245mm
Recommended cut out
diameter
206mm 246mm 246mm
Required depth
108mm 170mm 115mm 200mm 135mm 200mm
Weight
1.8kg 2.3kg 2.3kg 3.1kg 3.2kg 3.9kg
Back Can
- Yes - Yes - Yes
Tile bridge
- Yes - Yes - Yes
