Eclipse Combustion RatioMatic RM Series - Step 4: Ignition System

Eclipse RatioMatic v3.00 - Design Guide No. 110, 04/98
Ignition Transformer
For the ignition system, use a transformer with:
• secondary voltage 6,000 to 8,000 VAC.
• minimum secondary current 0.02 amps continuous.
• full wave output.
DO NOT USE the following:
• twin outlet transformer
• distributor type transformer.
Trial For Ignition
It is recommended that low fire start be used. However, under
certain circumstances RatioMatics are capable of direct spark
ignition at higher gas inputs.
Most local safety codes and insurance requirements limit the
maximum trial for ignition time (the time it takes for a burner to
ignite). These requirements vary from one location to another;
check your local codes and comply to the strictest codes
applicable.
The time it takes for a burner to ignite depends on the following:
• the distance between the gas shut-off valve and the burner.
• the air/gas ratio.
• the gas flow conditions at start-up.
The possibility exists where the low fire is too low to ignite the
burner within the maximum trial for ignition time. The following
options must be considered under these conditions:
• start at higher gas input levels.
• resize and/or relocate the gas controls.
• use bypass start gas.
3-6
Step 4: Ignition System
