System Design
DESIGN
Design structure
The design process is divided into the following steps:
1. Burner Option Selection including:
• Burner Model / Size Selection
• Fuel Type
• Air Supply
• Combustor Type
• Combustor Length
• Control Motor
• Burner Configuration
• Gas Pipe Connection
• Flame Supervision
• Air Flow Switch
2. Blower Option Selection including:
• Power Supply Frequency
• Pressure & Flow
• Blower Motor Type
• Blower Inlet
• Motor Orientation
3. Control Methodology including:
• Burner Control
4. Ignition System including:
• Ignition Transformer
• Trial For Ignition
• Ignition Gas Piping
5. Flame Monitoring Control System including:
• Flame Sensor
• Flame Monitoring Control
6. Main Gas Shut-Off Valve Train including:
• Component Selection
• Valve Train Size
