(e) Start battery monitor is green outlined
(f) Start battery contactor is engaged (green)
(g) L BBC contactor is engaged (green)
(h) R BBC contactor is disengaged (white)
(i) Bus tie is engaged (green)
(j) L FWD-AFT breaker is engaged (green)
(k) R FWD-AFT breaker is engaged (green)
(l) External power contactor is engaged (green)
(m) L GEN contactor is disengaged (white)
(n) R GEN contactor is disengaged (white)
NOTE: System & Start Battery Monitors “may” toggle from green to amber at times.
(23) Apply electrical power to the left hand ACS.
(24) On the INSTRUMENT PANEL, LEFT, Reset the following breaker:
• L Aircraft Computer System (L-ACS)
(25) On the MFD ECB synoptic page, use the inner DCK to select the AVIONICS system,
and the outer DCK to highlight the following ECB:
• ECB - L AIRCRAFT COMPUTER (R FWD Bus)
(26) On the MFD ECB synoptic page, select the RESET LSK.
