VTR output terminals
Connect to the monitor with video input.
Yellow : Video signal White : Audio (left) signal Red : Audio (right) signal
VTR input terminals
Connect to the output wire of external video main unit such as a VTR.
Yellow : Video signal White : Audio (left) signal Red : Audio (right) signal
G
H
Main unit connections
ACC ON/OFF power supply terminal (blue/white)
If you use this terminal to connect main unit such as an external amplifier, you can still hear the audio guidance
from the navigation system even when audio is turned off. Connect it to the control terminal for the external
amplifier or other main unit.
※
A popping noise may be heard when the engine is being started or the ignition switch is at the ON position, but
this is normal and is not the sign of a malfunction.
Back-eye camera external input terminal (4P)
Used with the Eclipse back-eye camera (sold separately).
E-LAN terminal (13P)
Connect to the E-LAN terminal of the CD changer, etc.
