Eclipse AVN 6600 - Vehicle Connections; Example of Using Vehicle Adapter Wires

-
9
-
Vehicle component adapter wires
Vehicle harness
From main unit
- Example of using vehicle adapter wires
-
-
Vehicle connections
-
Power supplies
for combined
equipment
Español Français Italiano
Nederlands
SvenskaEnglish
••
You will need to purchase the necessary vehicle component adapter wire for the vehicle so that the
power supplies can be utilized. (Contact the dealer for further details.)
••
Be sure to wrap the connection wires with electrical tape or another insulation method to insulate them.
Tip
