Eclipse AVN7000 Installation Manual

-
15
-
TO GROUND
GROUND CABLE
TV ANTENNA
(supplied with TVR105)
TV ANTENNA
(supplied with TVR105)
TO GROUND
5P
12P
5P
6P
FROM EXTERNAL VIDEO
EQUIPMENT
(remove cap when using
extenal VIDEO EQUIPMENT)
TO GROUND
TO GROUND
ANTENNA SELECTOR
(supplied with TVR105)
TO GROUND
DIGITAL OUT
(Do not remove cap)
CH3083
(sold separately)
DIN CABLE
(supplied with CH3083)
POWER CONNECTOR
CABLE
(supplied with CH3083)
INTERCONNECTING CABLE
(supplied with TVR105)
ANTENNA
PLUG
TO BATTERY+12V
(Permanent Supply)
Yellow
TO BATTERY+12V
(Permanent Supply)
TO GROUND
HDR105
(sold separately)
TVR105
(sold separately)
ANTENNA EXTENSION CABLE
(supplied with HDR105)
INTERCONNECTING CABLE
(supplied with TVR105)
PIN CABLE
(supplied with TVR105)
DIN CABLE
(supplied with HDR105)
Black
13P
13P
13P
Black
Black
Black
Yellow
13P
2P
TO BATTERY+12V
(Permanent Supply)
Yellow
INTERCONNECTING CABLE
(supplied with HDR105)
INTERCONNECTING CABLE
(supplied with TVR105)
TO ACC
(Power Supplied)
Tip*1
L
R
L
R
MidLowMidHi
FRONT
SWREAR
CENTER
L
R
L
R
MidLowMidHi
FRONT
SWREAR
CENTER
For a front 1-way speaker system
For a front 3-way speaker system
-
Speaker connection examples
-
Red
• See DCU 105 owners manual for details.
2P
To center speaker
(with amplifier) or
external amplifier
To sub woofer
(with amplifier) or external amplifier
To external amplifier
To external anplifier
To external amplifier
To external amplifier
To center speaker
(with amplifier) or
external amplifier
To sub woofer
(with amplifier) or external
amplifier
To external amplifier
To external amplifier
