Eclipse avn8826 Installation Manual

-
2
-
English English English English English English English
GPS antenna components
GPS antenna
x 1
14
Waterproof cushion
x 1
15
Earth plate
x 1
16
Body protective sheet
x 1
17
Interconnecting cable
(Speed pulse, parking,
reverse,video, etc)
(20P) x 1
3
Main unit
x 1
1
When installing the main unit, some vehicle models may require the use of items that need to be obtained
separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting bracket.
Tip
Interconnecting cable
(Power and speaker connector)
(16P) x 1
2
Main unit components
Interconnecting cable
(E-lan etc)
(16P) x 1
4
Wiring components
Cable tie
x 4
19
Harness affixing tape
x 3
20
Mounting sleeve
x 1
7
Antenna cable
x 1
5
Bezel
x 1
6
Side bracket
x 2
8
Clamp
(for GPS antenna) x 3
18
Case
(For detachable panel) x 1
9
Splicing connector
x 3
10
Flat head screw
(M4x6) x 4
11
Thin flat screw
(M4x5) x 4
12
Pan screw with washer
(Blue:M4x3) x 4
13
Components
Components
Check that all of the following components are present
Check that all of the following components are present
