Eclipse GEO User Manual

1
1
2
SCREW QTY DESCRIPTION
TECH FLEX MAT
Protect your Geo whilst you
maintain it with the Eclipse Tech
Flex Mat.
GEO COMPREHENSIVE SPARES KIT
Replacement spares to service your
Geo (not all spares shown).
ECLIPSE GUN OIL
The recommended oil to use on
all maintenance and servicing
procedures that require oil.
ECLIPSE TECH SHIRT
The perfect pocket covered
garment for carrying all those hex
keys and spares for your Geo.
ECLIPSE EGO9
The perfect kit bag companion to
the Eclipse Geo. The Eclipse Ego9 is
our most advanced Ego to date.
ECLIPSE GREASE
The recommended grease to use
on all maintenance and servicing
procedures that require grease.
PCB SCREW (3), BEARING CARRIER (2)
( M2.5 x5 CAP HEAD SOCKET)
RUBBER GRIP SCREW (6), BBSS COVERS SCREW (2)
( 6-32UNC x5/16 COUNTERSUNK SOCKET)
SHORT FEED NECK SCREW
( 1 x10-32UNF x1/2 CAP HEAD SOCKET)
INLINE REGULATOR ADJUSTER SCREW
( CUSTOM MANUFACTURED)
MICRO-SWITCH SCREW
( 6-32 UNC x1/2 SOCKET SET SCREW)
TRIGGER ADJUSTMENT SCREW
( 6-32 UNC x3/16 SOCKET SET SCREW)
T-RAIL SCREW
( 10-32 UNF x1/2 SOCKET SET SCREW)
SHORT REAR FRAME SCREW
( 10-32 UNF x3/8 SOCKET BUTTON HEAD)
5
8
1
1
1
5
2
1
LONG FEED NECK SCREW
( 1 x10-32UNF x5/8 CAP HEAD SOCKET)
1
BODY PLUG
( CUSTOM MANUFACTURED)
LONG FRONT FRAME SCREW
( 10-32 UNF x3/4 SOCKET BUTTON HEAD)
SOLENOID (2)
( M2.5x12 CAP HEAD SOCKET)
PARTS lIST
82.
CONTENTS
ORIENTATION
QUICK SET-UP
USING YOUR GEO
ADVANCED SET-UP
MENU TREE
MAINTENANCE
FAULT FINDING
SERVICE CENTERS
PARTS LIST
SPARES & ACCESSORIES
83.
SPARES
SPARES & ACCESSORIES
QUICK GUIDE

Eclipse GEO Specifications

General

Manufacturer	Planet Eclipse
Power Source	9V Battery
Caliber	.68
Firing Modes	Semi-Auto, Ramping, Full Auto
Rate of Fire	20+ BPS
Height	200mm
Air Source	High Pressure Air (HPA)
