Eclipse Veri-Flame Instruction Manual 818-2/02
Lockout Main valve has been energized and main flame proven during trial
for ignition.
Status Pilot valve is de-energized and main flame is on.
Lockout For purge and no purge models: Main valve closed switch is
open before start-up or after burner shutdown.
Lockout For purge & modulation models: No purge time was selected;
lockout prior to purge to high fire.
Lockout Pilot flame was not established during the pilot trial for ignition.
Status Pilot flame is proven; transformer is de-energized; remaining count-
down for pilot trial for ignition is.
Status Pilot valve and ignition transformer are energized; countdown for
pilot trial for ignition begins.
Status For purge & modulation models: 15 second post purge is
started on burner shutdown.
Lockout DIP switch improperly set or changed during cycle.
Status For modulation models only: Modulating motor is sent to high
fire.
Status For modulation models only: Modulating motor is sent to low
fire.
Lockout Internal relay(s) fail initial check. Check ratings. If lockout still oc-
curs after overload is eliminated, replace control.
Status Control has completed internal safe-start check.
Status For purge & modulation models: Combustion air switch is closed
before start-up or after shutdown; control holds start-up until switch
reopens; if interlocks close before switch opens, alarm is energized.
Lockout For purge & modulation models: Same conditions as above,
except the interlocks close before the switch reopens, causing a
lockout and the alarm being energized.
MESSAGE TYPE EXPLANATION
Table 9.2
Remote Display Diagnostic Messages (continued)
MAIN FLAME ON
MAIN FLAME ON
PILOT OFF
MAIN VALVE FAIL
XX:XX:XX LOCKOUT
NO PURGE SELECT
XX:XX:XX LOCKOUT
PILOT FLAME FAIL
XX:XX:XX LOCKOUT
PILOT ON
PILOT TRIAL FOR
IGNITION
POST PURGE
PROGM SWITCH ERR
XX:XX:XX LOCKOUT
PURGE TO HIGH
FIRE
PURGE TO LOW
FIRE
UNSAFE AIR SHORT
SAFE START OK
UNSAFE AIR SHORT
XX:XX:XX LOCKOUT
RELAY FAIL
XX:XX:XX LOCKOUT
To Next Page
