Eclipse Veri-Flame Instruction Manual 818-2/02
Specifications
INTRODUCTION
Specifications
This section gives a detailed overview of Veri-Flame specifications and dimensions.
2
(continued onto next page)
P ARAMETER D ESCRIPTION
Supply • Series 5602 & 5605: 120 VAC (
+
10%,
-
15%), 50/60 Hz standard.
Series 5603: 240 VAC (
+
10%,
-
15%), 50/60 Hz standard.
Internal power consumption: 12 VA (excluding external connected loads).
Temperature Ranges
Unit Model Nos. Temperature Range
Veri-Flame All Models -40˚ to +60˚C (-40˚ to +140˚F)
90˚ U.V. Scanner 5600-90A -20˚ to +60˚C (0˚ to 140˚F)
U.V. Scanner 5600-91 -20˚ to +125˚C (0˚ to +257˚F)
NEMA4 UV Scanner 5600-91N4 -20˚ to +125˚C (0˚ to +257˚F)
I.R. Scanner 5600-92B -40˚ to +110˚C (-40˚ to +230˚F)
UV/IR Scanner 5600-92SC -20˚ to +80˚C (0˚ to +176˚F)
Self-Check U.V. 5602-91 -20˚ to +60˚C (0˚ to +140˚F)
Remote Display 5602DB 0˚ to 50˚C (32˚ to 122˚F)
Remote Display 5602DBP 0˚ to 50˚C (32˚ to 122˚F)
Flame Failure Response 3 seconds ±0.5 seconds.
Trial For Ignition (TFI) No Purge & Purge Models:
Series 5602 & 5603: five or 10 seconds selectable.
Series 5605: ten or 15 seconds selectable.
Modulating Model: 5 or 10 seconds selectable
Pilot Interrupt (if selected) 10 seconds.
Purge Time Selectable from 0-225 seconds in 15 second increments.
Output Ratings
for
120 VAC
Function
Terminals
Inductive Load
(maximum total connected
Gas Valve 3, 5 175VA, 1/10 HP 10 amps
load not to exceed 15 amps)
Ignition 4 375 VA 10 amps
Motor or Contactor
8 470 VA, 1/2 HP 16 amps
Output Ratings
for
240 VAC
Function
Terminals
(maximum total connected
Valves, Ignition
3, 4, 5,
5 amps
load not to exceed 15 amps)
Motors or Contactor
8
5 amps
Alarm
10, 11, 12, 13 5
amps
UL, CSA
Control Signal
A, 10, 11, 12, 13
175VA
10 amps
Relay Contact Rating
Resistive Load
Control
16 amps
A
Relay Contact Rating
Resistive Load
