ECO Charge FS3 - Installation and Configuration; AC Input and Busbar Connection

6. Installation
Installation
Charger
Model
Number
Charger
Modules
Supply
Phase
DC
Output
Supply
Voltage
AC Supply
in Max.
Amps.
Per Phase
Aux.
Plug
Busbar
Selection
Config.
Number
FS3LUE-
512
2x
MP130
Single
Phase
24/36/
48V
208-
240
28-
30*
J5 1/2
FS3LUE-
522
2x
MP130
Three
Phase
24/36/
48V
208-
240
15.5-
23.2**
J5 3
FS3LUE-
513
3x
MP130
Single
Phase
24/36/
48V
208-
240
28-
30*
J5 1/2
FS3LUE-
523
3x
MP130
Three
Phase
24/36/
48V
208-
240
13.3-
27**
J5 3
FS3LUE-
532
2x
MP330
Three
Phase
24/36/
48V
380-
480
8-
10
J6 4
FS3LUE-
533
3x
MP330
Three
Phase
24/36/
48V
380-
480
12-
15
J6 4
AC Input & Busbar Connection
Charger Model Number
FS3LUE-5xy
FS3 = Frame size.
MPx30 = 1 for MP130 or 3 for MP330.
y = 2 or 3 modules installed.
* in single phase mode the output power will reduce to maintain maximum AC current draw.
** in three phase mode the adding of the third charger module reduces the AC current draw
to achieve the same DC output as for two modules.
