Low battery flash
2.10. CABLE DEFINITION
1. Red: Battery +
2. Blue: Weak lock
3. Black: Battery-
4. Green: UART-RECEIVE (RXD)
5. White: UART- SEND (TXD)
2.11. AUTO SLEEP AFTER 10 MINUTES
When the riding speed is less than 2 km/h for 10 minutes, the system will go to
sleep automatically.
2.12. Error code table
The error code is corresponding with the fault definition.
Error code
definition
21
Current error or MOS damaged
22
Throttle error(Start detection)
23
motor no phase position
24
Hall error
25
Brake error(Start detection)
9
communication display receiving error
3. Using the bike
3.1. Riding the bike
Before each start, make sure that your bike is technically sound and check the
following items in particular:
• Properly tighten the screws.
• Fasteners or any parts of the bicycle are not damaged.
• Is the ride position adequate?
• Proper steering wheel alignment.
