LEGEND:
A - On/Off knob
B - Domestic hot water temperature
adjustment knob (summer)
C - Water ignition failture L.E.D.
(red)
D - Central heating selection
(winter) and temperature
adjustment knob
E - Heating system working L.E.D.
(green)
F - Fume sensor L.E.D. (yellow)
G - Ignition failure (lockout)
L.E.D. (red)
H - Ignition failure (lockout) and/or
overheat reset button
I - Overheat L.E.D. (red)
L - Central heating temperature
L.E.D (yellow)
M - Arrangement for programming
time clock (optional)
N - Heating system pressure gauge
