Ecoflam MAX P 35 AB User Manual

A1 TCH 2xx control box
M1 Electric motor for pump and
blower wheel
T1 Ignition transformer
Y1 Solenoid valve
3 Air regulation in the burner head
5 Fastening screws for equipment plate
15 Burner flange
16 Display
102 Fuel-oil pump
103B Air regulation
113 Air intake
AB TC - 230-50 TWMAX P 35
MAX P Light oil soft start
RANGE NAME BY FUEL TYPE
35 36 kg/h
MODEL SIZE (Gas: kW; Oil: kg/h)
- Standard Class 2-OIL EN267 (<185 mg/kWh)
Low NOx Low NOx Class 3 yellow flame (<120 mg/kWh)
EMISSION COMBUSTION TYPE
- 1 stage
AB 2 stage
OPERATION TYPE
TC Short head
TL Long head
HEAD TYPE
- Light oil
KER Kerosene
B10 Biodiesel
FUEL
230-50 230 Volt, 50 Hz
ELECTRICAL SUPPLY TO THE SYSTEM
Contents
- Burner description
Scope of delivery
CB: COMPLETE BURNER
- 1 bag including :
- multilanguage technical manual.
- filter and hoses.
- nozzle and spanner.
- screws, nuts and washer.
KIT & ACS delivered separately
T1
113
103B
5
Y1
A1
M1
15
16
102
3
TW Thermowatt
CONTROL BOX
420010492200
EN
7

Ecoflam MAX P 35 AB Specifications

General

Brand	Ecoflam
Model	MAX P 35 AB
Category	Burner
Language	English
