41
Connectivity
Bluetooth frequency 2,400-2,483.5 MHz
WiFi frequency 2,400-2,483.5 MHz/5,725-5,850 MHz
Cellular network
Europe
LTE-FDD: B1/B3/B7/B8/B20/B28
North America
WCDMA: B2/B4/B5
LTE-FDD: B2/B4/B5/B12/B13/B25/B26
Disc
parameters
Rated speed
Gentle: 0.4 m/s
Normal: 0.6 m/s
Quick: 0.8 m/s
Maximum speed 0.8 m/s
Drive mode Direct-drive hub motor
Blade motor
Rated speed 2,800 rpm
Maximum speed 3,000 rpm
Motor type Brushless motor
Battery
Battery type Lithium-ion battery
Nominal capacity 21.6V
Nominal capacity 298Wh
Protection system
Over-heat, short-circuit, over-current, over-
voltage, under-voltage
Charging
station
Input voltage 36 V
Input current 5 A
Output voltage Max. 25.2 V DC
Output current Max. 7A
Other
Front wheel 200 mm (7.9 in.) omnidirectional wheel
Rear wheel
Hub motor with rubber tyres
Sensor
IM sensor, Lift sensor, rain sensor, wheel
encoder, RGB-D camera
Vertical obstacle crossing
ability
40 mm (1.6 in.)
1. The above data was measured in a laboratory and is for reference only.
2. The noise emission declar
ations conform to EN 50636-2-107 and ANSI/OPEI
60335-2-107.
3. The manufacturer reserves the right to make modications without notice, please
go to www.ecoow.com for the latest specications or related documents.
