EcoFlow DELTA 2 User Manual

1
1. Specifications
Input Ports
AC Charging
AC Input Voltage
Solar Charging
Car Charging
X-Stream Fast Charge 1200W max
220-240V~ 10A, 50Hz/60Hz
11-60V 15A Max, 500W Max
Supports 12V/24V Battery, Default 8A
Max Device(s) Power Supported by
X-Boost
USB-A (x2)
USB-A Fast Charge (x2)
USB-C (x2)
Car Charger
DC5521 Output (x2)
5V 2.4A, 12W Max per port, total 24W
5V 2.4A 9V 2A 12V 1.5A, 18W Max per port, total 36W
5/9/12/15/20V 5A, 100W Max per port, total 200W
12.6V 10A, 126W Max
12.6V 3A, 38W Max per port
General Info
Output Ports
Net Weight
Dimensions
Capacity
Wi-Fi
Bluetooth
Approximately 12kg (27lbs)
400x211x281mm (15.7x8.3x11.1in)
1024Wh, 51.2V
Supported
Supported
Battery Info
Cell Chemistry
Cycle Life
LFP
3000 cycles to 80%+ capacity
* A car charger shares power with the DC5521 output port, offering a maximum output of 126W.
AC (x4)
Pure Sine Wave, 1800W total (surge 2700W),
230V~ (50Hz/60Hz)
2400W
Protection
Over Voltage Protection, Overload Protection,
Over Temperature Protection, Short Circuit
Protection, Low Temperature Protection, Low
Voltage Protection, Overcurrent Protection

EcoFlow DELTA 2 Specifications

General

Fast charging	Yes
Charging source	AC, Cigar lighter, Solar
Battery capacity	- mAh
Battery technology	Lithium Iron Phosphate (LiFePO4)
Total output power	2200 W
USB Type-A output power	2 W
Number of charging cycles	3000
Number of simultaneously connected devices (max)	-
Control type	Buttons
Certification	UL CE FCC RoHS PSE
Product color	Black
AC outlets quantity	6 AC outlet(s)
USB Type-A output ports	2
Storage temperature (T-T)	-10 - 45 °C
Operating temperature (T-T)	20 - 30 °C
Cables included	AC, Cigar lighter

Weight and Dimensions

Depth	281 mm
Width	211 mm
Height	400 mm
Weight	12000 g
