ELECTRICAL SPECIFICATIONS
Each ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ® Model 5.0
model has very specific wiring requirements based on its line voltage and
amperage draw.
•
Model 5.0 operates at 110 – 120v. A power cord will be supplied out of the
power box. Plug this into any standard 110 – 120v outlet. As above, the
cord labeled ORP must be plugged into a controller, or a 120v outlet.
•
Your ECOLAB Aqua Balance Pure Comfort Mineral Pool & Spa ®
Model 5.0 system must be wired to the main pump power supply, so that
if the pump is shut down, the power to your ECOLAB Aqua Balance Pure
Comfort Mineral Pool & Spa ® system is lost.
ELECTRICAL SPECIFICATIONS AND FUSE SIZING
AMPS
VOLTAGE
REQUIRED
Fusesizing:
Model Fuse size and type
5.0 20amp dual element, slow blow, RK5 fuse
