3
1. Description
The satellite in the Chameleon ran-
ge is a complete hygiene station
which is connected to a booster or
a main station. Therefore the satel-
lite must be supplied with water in
suffi cient quantity, (power supply)
compressed air, detergent(s) and
disinfectant. The station is then
ready for hygiene duties.
Fig. 2 0627088 Fig. 3 0627127
The Advanced satellite incorpora-
tes a unique pneumatically con-
trolled valve system that ensures
injectors are fl ushed with water
between hygiene functions. De-
pendent on the model the system
can work automatically or pneuma-
tically via the selector.
Using hygiene Chemicals
The Advanced Satellite has been
prepared to use Ecolabs European
palette of detergents and disinfec-
tants.
Warning: Do not change the set-
tings made or recommended by
the supplier of hygiene chemicals.
A typical installation of the Advan-
ced series is shown in fi g. 1
Main station (1)
Mixing system (2)
Satellite (3)
Detergents are supplied either
from the User Pack System, which
can be ordered and delivered as
an accessory or from separate
standard cans. Hygiene chemicals
can also be established through
piping systems.
Fig. 1 0627103
1
3
2
Important: Do not use the water from
the system for applications other than
cleaning.
