Ecolab XP Foamer - XP Foamer Component Layout

6
110002426
1
2
3
12
9
8
6
7
5
4
10
2
1
11
3 11
English (EN)
3.1. Layout for XP FOAMER.
Single user unit
1. Water inlet
2. Pump
3. Flow Switch
4. Injector block
5. Chemical inlet, block
6. Sanitaizeer inlet, block
7. Air inlet, block
8. Compressor
9. Water outlet
10. Switch, Compressor
11. Control box
12. Power supply
