Unit Specifications: Thermal-Duct
TM
air handlers
MODEL
TDHV-
12
TDHV-
18
TDHV-
24
TDHV-
30
TDHV-
36
TDHV-
42
TDHV-
48
TDHV-
60
Number of 3”
outlets
1
8 12 15 18 22 26 30 36
Cooling Capacity
(Tons)
1.0 1.5 2.0 2.5 3.0 3.5 4.0 5.0
*Heating Capacity
(MBH) 130F water
15 21 35 41 46 49 52 57
*Heating Capacity
(MBH) 140F water
18 25 41 48 54 57 61 67
*Heating Capacity
(MBH) 160F water
24 33 53 62 69 74 78 86
*Heating Capacity
(MBH) 180F water
30 40 65 76 85 91 96 105
(USGPM) Heating 2.3 2.3 4.5 4.5 4.5 4.5 4.5 4.5
Nominal Airflow
(CFM)
2
360 540 720 900 1080 1260 1440 1800
Max. Design ESP
Heat Only (“WC)
1.0 0.8 0.9 0.7 0.8 0.6 1.0 0.5
Max. Design ESP
Heat/Cool (”WC)
3 0.9 0.7 0.8 0.4 0.5 0.3 -- --
Blower Motor Full
Load (Amps)
4 4 5 5 7 7 10 10
Circulator Full
Load (Amps)
0.6 0.6 0.8 0.8 0.8 0.8 0.8 0.8
1. Minimum Required. Refer to Design and Installation Instructions for options.
2. All air flows at high speed.
3. Using Ecologix cased slab cooling coils. Above 3.5 tons, use an A-coil.
