Physical Properties
Cabinet dimensions Supply air Return air water
inlet
Shipping
Model Type a b c d x e f x g and
outlet
Weight
TP30, TDHV-12,
TDHV-18
20” 14” 24” 12”x16” 12”x16” 1/2” 80 lb.
TP45 to TP75,
TDHV-24 to
TDHV-60
22” 22” 31.5” 20”x20” 20”x20” 3/4” 110 lb.
Unit Specifications: thermal-pac
TM
air handlers
MODEL: TP30 TP60 TP65 TP75
*Heating Capacity (Btu/h) 120F water
21,000 43,000 47,000 55,000
*Heating Capacity (Btu/h) 130F water
28,000 56,000 61,000 71,000
*Heating Capacity (Btu/h) 140F water
30,000 60,000 66,000 77,000
*Heating Capacity (Btu/h) 160F water
37,000 77,000 85,000 100,000
*Heating Capacity (Btu/h) 180F water
48,000 95,000 104,000 122,000
(USGPM) Heating
2.3 4.5 4.5 4.5
Maximum Heating Airflow (CFM)
800 1200 1400 1900
Max. External Static Pressure (“wc)
0.3 0.4 0.5 0.3
Cooling Capacity – High (Tons)
2.0 3.0 3.5 5.0
Blower Motor Full Load (Amps)
5 5 7 10
Circulator Full Load (Amps)
0.6 0.8 0.8 0.8
*based on 70F return air, high fan speed and 20F water temperature drop through the coil.
