ECOPURE ECOP30 - Page 25

25
To order repair parts call toll free 1-800-693-1138.
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
Ù Please purchase replacement cartridges from the retailer where you bought your reverse osmosis system.
¢ Not illustrated.
= Not included.
p Tubing lengths for remote installations, direct replacement for colored lengths of tubing.
NOTE: Codes in the state of Massachusetts require installation by a licensed plumber and do not permit the
use of saddle valves.
Parts List
Key
No.
Part No. Description
– 7333129
Mounting Hardware Kit
(includes 2 ea. of Key Nos. 1 & 2)
1
á
Screw (2 req’d)
2
á
Hanger Washer (2 req’d)
– 7333137
Check Valve Kit
(includes Key No. 4 & 2 of Key No. 3)
3
á
O-ring, Auto. Shutoff Cover (2 req’d)
4
á
Check Assembly
– 7333145
Automatic Shutoff Kit (incl. Key No. 7,
4 of Key No. 6 & 6 of Key No. 5)
5
á
Screw (6 req’d)
6
á
Washer (4 req’d)
7
á
Automatic Shutoff Cover Assembly
– 7333179
Diaphragm Kit (includes
Key Nos. 9, 10 & 2 of Key No. 8)
8
á
Diaphragm (2 req’d)
9
á
Plunger
10
á
Spacer Ring
– 7333153
Flow Control Kit
(includes Key Nos. 11 & 12)
11
á
Flow Control Insert
12
á
Elbow, Plug-in, 1/4 Stem x 1/4 Tube
Key
No.
Part No. Description
13 ECOROF
Pre & Post Filter Cartridge Ù
14 ECOROM
RO Membrane Cartridge Ù
15 7205326 Storage Tank
– 7333161
Tank Connector Kit
(includes Key No. 16-18)
16
á
Nut, 3/8” Tubing
17
á
Insert, 3/8” Tubing
18
á
Connector, 1/4 NPT x 3/8 Jaco
19 119-8600123 Drain Adapter
20 119-8600084 Water Supply Fitting, 1/4” Q.C.
21 7292682 Faucet, with base and electronics
22 7272763 Cover
23 7322966
Repl. Head Assembly
(includes Key Nos. 3-10)
¢
7301203
Sanitization Kit =
¢
7315189
Auxiliary Storage Tank =
¢
7161823
Tubing, 1/4” x 20’ - white p =
¢
7157280
Tubing, 3/8” x 20’ - white p =
¢
7314183 Coin Battery
¢
7279749 Dropper
¢
1149-01-AB Owner’s Manual
