Wall Mounted Installation
1. Take out the wall brackets and expansion screws from the box. Fix the screws
onto the wall according to the distances between the holes of the wall brackets,
as depicted below:
2. Slot the hooks and tongues of the brackets into the corresponding notches at the
back of the heater. Pull the brackets up until they slot into place, as shown below.
3. On the top of the right bracket, fix the wall bracket lock piece as pictured. Fix the
lock piece loosely onto the bracket with the supplied screw. Slide the lock piece
into the locking slot on the back of the heater, then tighten up the screw.
