ECOVACS WINBOT 930 - Attach the Cleaning Pad; Assemble the Power Adapter; Install the Safety Tether

EN EN
7
3. Operating the Robot
3.2 Attach the Cleaning Pad
3.4 Install the Safety Tether
Turn WINBOT 9 over and attach the
Cleaning Pad to the Velcro smoothly. Make
sure the Cleaning Pad is placed exactly
within its Velcro area.
A
B
C
DD
If WINBOT 9 is used to clean an outside window, the Safety Pod and
Tether MUST be used.
3.3 Assemble the Power Adapter
If WINBOT 9 is being used to clean an inside window, please skip to step 3.6.
*
End A: Robot Power Cord
End B: Power Adapter Power Cord
End C: Safety Pod End D: Safety Tether
