BMW S54 DUAL VANOS REBUILD
®
Return to Vanos Repair Table of Contents
Step 21:
Step 22:
Install the new o-rings into place on the large and small ends.
Lubricate the large o-ring with clean engine oil and push the oil regulator
into place in the piston housing. Be sure to locate the holes at the sides as
shown.
- End of Section 3b -
SECTION 3B: VANOS OIL SYSTEM SERVICE
