BMW S54 DUAL VANOS REBUILD
®
Return to Vanos Repair Table of Contents
Step 17:
Step 18: 5mm Allen (Hex Bit) Socket, Torque Wrench
Install the new seal onto the piston cap and lubricate it with clean engine
oil.
Install the intake piston cap and torque the bolts to 10 Nm (7 Ft-lbs).
SECTION 3C: INTAKE PISTON SEAL REPLACEMENT
10 Nm (7 Ft-lbs)
- End of Section 3c -
