ECS 945GCD-CI - PC Health Status

34
Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
System Temperature : 29°C/84°F
CPU Temperature : 25°C/77°F
SYS FAN Speed : 3729 RPM
CPU Core : 1.088 V
VDIMM : 1.792V
+3.3V : 3.392 V
+5.00V : 4.999 V
+12.0V : 11.968 V
5VSB : 5.026 V
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
Press <Esc> to return to the main menu setting page.
• System/CPU Temperature
• SYS FAN Speed
• CPU Core
• VDIMM
• +3.3V
• +5.00V
• +12.0V
• 5VSB
