6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket FM1 for AMD A series processors
2. SYS_FAN System cooling fan connector
3. CPU_FAN CPU cooling fan connector
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SPI_DEBUG SPI debug header-for factory use only
7. SATA1~6 Serial ATA 3.0 Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. SPDIFO SPDIF out header
10. CLR_CMOS Clear CMOS jumper
11. F_USB1
Front panel USB 2.0 header˄with EZ Charge function˅
12. F_USB2 Front panel USB 2.0 header
13. SPK Speaker header
14. LPT Onboard parallel port header
15. COM Onboard serial port header
16. CASE Case open header
17. PCI 32-bit add-on card slot
18. PCIE1~2 PCI Express x1 slots
19. PCIEX16 PCI Express slot for graphics interface
20. F_AUDIO Front panel audio header
21. ATX12V 4-pin +12V power connector
